Overview
FSS430
Swirl flowmeter for vapor, liquid and gas, with optional graphical display, optional binary output and optional integrated temperature measurement.
FSS450
Swirl flowmeter for vapor, liquid, and gas, with integrated digital output, temperature compensation and flow computer functionality. The device offers the option of directly connecting external temperature transmitters, pressure transmitters, or gas analyzers.
| Model number | FSS430 | FSS450 |
| Design | Integral mount design, remote mount design | |
| IP degree of protection in accordance with EN 60529 | IP 66 / 67, NEMA 4X | |
| Measuring accuracy for liquids | ≤ ±0.5 % under reference conditions | |
| Measuring accuracy for gases and vapors | ≤ ±0.5 % under reference conditions | |
| Repeatability | DN 15 ≤ ±0.3 %, from DN 20 ≤ ±0.2 % | |
| Permissible viscosity for fluids | DN 15 … 32 ≤ 5 mPa s, DN 40 … 50 ≤ 10 mPa s, from DN 80 ≤ 30 mPa s | |
| Measuring span (typical) | 1:25 | |
| Process connections | Flange DN 15 .. 400 (0.5″ … 16″) | Flange DN 15 .. 400 (0.5″ … 16″) |
| Inlet / outlet sections (typical) | Inlet section: 3 x DN, outlet section 1 x DN, see also chapter „Inlet and outlet sections“ | |
| Temperature measurement | Resistance thermometer Pt100 class A optional, installed in Piezo sensor, can be retrofitted | Resistance thermometer Pt100 class A standard, fixed installation in Piezo sensor |
| Permissible measuring medium temperature | -55 … 280 °C (-67 … 536 °F) | -55 … 280 °C (-67 … 536 °F) |
| Wetted material | ||
| — Sensor | Stainless steel, optional Hastelloy C-276 / titanium | |
| — Inlet / outlet pipes | Stainless steel, optional Hastelloy C-276 | |
| — Gasket | PTFE, optional Kalrez or graphite | |
| — Sensor housing | Stainless steel, optional Hastelloy C-276 | |
| Sensor design | Piezo sensor with two pairs of sensors for flow measurement and vibration compensation | |
| Approvals for explosion protection | ATEX / IECEx, cFMus, NEPSI | |
===========
