Highly reliable, compact magnetic drive pumps
Features
- Highly reliable, compact magnetic drive pumps. Field-proven reliability. A large number of pumps in this series have been delivered to customers at home and abroad, earning high acclaim for their superior reliability. This is the best-selling series in the world.
- An incomparable range of models available. The MD series comes in a total of 38 models. A wide range of flow rates, hose connections, and threaded connections (M type) are available as standardized models. In addition, dedicated high-head, large-flow-rate models are available. The most economical and suitable pump can be selected from this wide variety of models.
- Leakage-free, sealless structure. As is common with corrosion-resistant pumps, this series uses the magnetic drive method, eliminating problems caused by liquid leakage.
- Superior corrosion resistance. The pumps in this series are constructed mainly with polypropylene while at the same time using superior corrosion-resistant parts manufactured from ceramics, PTFE, and FKM. Therefore, they can be used to transfer strong acids and various other chemicals.
- Simple and compact. The pump structure is extremely simple. Consisting of several unitized parts, the pump is easy to maintain.
Specifications (50/60Hz)
| Max. discharge capacity range | 5.5 – 135 / 6 – 135 L/min |
|---|---|
| Max. head range | 1 – 14.3 / 1.4 – 20.3 m |
| Main materials | GFRPP |
| Required power range | 5 – 265W |
| Power supply | AC100V, 200V |
| Liquid temperature range | 0 – 80˚C |
| Specific gravity limit | Up – approx. 1.3 (depending on model) |
| Sealing method | Seal-less construction |
